Plug-and-Play USB Camera Modules for Pro Devices
From prototypes to production: UVC-compliant USB 2.0 and USB 3.x camera modules with onsemi, Sony, OMNIVISION, SmartSens, GalaxyCore, Himax, and more. Driverless on Windows, Linux, macOS, and Jetson.
UVC Plug-and-Play & Custom
CameMake designs and manufactures production-ready USB camera modules for OEMs, integrators, and product developers worldwide. Choose from compact board-level or enclosed USB 2.0/3.x models with rolling or global shutter, wide or narrow field of view, and resolutions from VGA to 48MP. Every unit is UVC plug-and-play for instant recognition — no driver headaches. For custom projects, we tailor sensor choice, lens, form factor, and connectivity to your exact needs.
Featured USB Camera Modules – Ready to Buy
Your Dynamic Snippet will be displayed here... This message is displayed because you did not provide both a filter and a template to use.
Why OEMs Choose CameMake USB Camera Modules
True plug-and-play
Our USB 2.0 and USB 3.x camera modules are UVC compliant, instantly recognized by Windows, Linux (V4L2), macOS, and Jetson — no drivers or complex setup.
Performance headroom
USB 3.x bandwidth for 4K/120fps; USB 2.0 options for low power.
Top-tier sensors
We integrate sensors from onsemi, Sony, OMNIVISION, SmartSens, GalaxyCore, Himax, and more — matching pixel size, dynamic range, and cost to your project.
Optics that fit
Custom FOV from narrow telephoto to 200° fisheye. IR-cut and IR-pass options available for visible or NIR imaging.
Tuned image quality
Factory white balance, color matrices, lens shading, and ISP pipelines.
Built for Production
As a direct manufacturer, we provide serial labeling, QA reports, calibration data, and long-term supply support. Essential for scaling your product.
Applications
Industrial & Robotics
USB camera modules shine on production lines and robot cells where fast setup matters. Our UVC-compliant USB 2.0 camera modules plug into any PC or edge box without drivers, making them ideal for vision tasks like pick-and-place, dimensioning, and guidance. Choose global shutter for motion, pair with hardware trigger/strobe I/O, and run at high FPS for precise timing.
Access Control, Kiosks & Self-Service
For kiosks, turnstiles, and smart terminals, USB 3.x camera modules deliver reliable, plug-and-play UVC video to Windows/Linux systems—perfect for ID checks, document capture, and face-aware UX. Go 4K rolling shutter for crisp color, or low-light sensors for dim lobbies. Lock focus at the factory, add IR-cut/IR-pass variants, and select board-level or enclosed modules depending on your mechanical stack.
Smart Retail & Edge AI Analytics
Build people counting, queue analytics, and planogram checks with board-level USB camera modules that run on common AI boxes (Jetson®, x86) using standard UVC pipelines. Wide-FOV lenses cover more shelf space; low-light/HDR maintains detail under mixed lighting. If privacy is a must, mono sensors and fixed exposure modes keep processing on-device.
Drones, AMRs & Mobile Robots
When every gram and watt matter, our lightweight USB camera modules offer dependable imaging for AMRs, AGVs, and UAVs without custom drivers. Use global shutter for fast motion and visual odometry; choose compact board shapes, right-angle connectors, and secured cables for vibration resistance. We support a broad sensor portfolio.
Customization – Direct from the Manufacturer
Your product, your camera. As the direct manufacturer, CameMake can customize your USB camera module to meet your exact mechanical, optical, and electrical requirements, while keeping UVC plug-and-play compatibility.
What We Customize:
- Resolution & Sensor: HD to multi-megapixel; onsemi, Sony, OMNIVISION, SmartSens, GalaxyCore, Himax,...
- Shutter Type: Rolling or global.
- Lens & FOV: M12, CS, C-mount; IR-cut or IR-pass; 30°–200°.
- Form Factor: Board shape, mounting holes, enclosed or board-level.
- Connectors & Cables: USB-A, USB-C, right-angle, custom lengths.
- Branding: Labeling, serials, QA reports, compliance documentation.
Process:
- Share your requirements (sensor, FOV, size, FPS, environment).
- Receive a proposed configuration and quote.
- Evaluate your samples before production.
Image Sensor Partners
FAQ: USB Camera Modules
A USB camera module is a board-level or enclosed camera built for integration into products. Unlike consumer webcams, it’s designed for OEMs/ODMs - stable parts, consistent image quality, and options for lenses, form factors, and connectors.
Yes. Our modules are UVC-compliant, so they work plug-and-play on Windows, Linux (V4L2), macOS, and common edge devices (including Jetson) without custom drivers.
Yes. Many customers run multi-camera setups. Use powered USB hubs, plan bandwidth per port, and set per-camera exposure/FPS to avoid contention. We can share working reference layouts.
A broad portfolio: onsemi, Sony, OMNIVISION, SmartSens, GalaxyCore, Himax, and more. We’ll match pixel size, dynamic range, and cost to your scene and budget.
RoHS/REACH as standard. If you need additional compliance or documentation for your industry, let us know and we’ll advise per model.
Yes. CameMake designs and supplies USB camera modules directly to OEMs and integrators. You work with our engineering and sales team, no middlemen.
- Samples: 10 units (usually quick ship).
- Pre-production: 100 units.
- Production: MOQ depends on configuration.
Lead times vary by sensor/lens stock; we’ll confirm on your quote
UVC USB Camera Modules – Sensor & ISP Options Table
| ISP name | Image-sensor brand | Image-sensor name | Decoder / format | Megapixel capability | FPS capability | ISP remarks |
| 2688A | GalaxyCore + OmniVision | 2099N + GC03A3 | RAW (MIPI) | VGA + 3 MP | Windows Hello | IR pair |
| 2075A / 2085A / 2087S (narrow-bezel) | onsemi (Aptina) / — | A2020 / CV1351 | RAW / MIPI | 1 MP | — | Max still: 1280×800 |
| 2282B / 2093N (narrow-bezel, TNR) | onsemi (Aptina) / — | A2020 / CV1351 | RAW / MIPI | 2 MP | 60 fps | Max still: 1280×960 |
| 2089D / 2150A2 (built-in digital mic; AF optional) | onsemi / — | A2020 / CV1351 | RAW / MIPI | 2 MP | — | Max res 1280×800 |
| SN9C2285A | onsemi (Aptina) | AR0130 | YUY2 / MJPG | ≤720p | 30 fps | — |
| SN9C5256AJG | onsemi (Aptina) | AR0130 | YUY2/MJPG | ≤960p | 30 fps | Beauty mode |
| SN9C291BIG | onsemi (Aptina) | AR0130 | YUY2/MJPG/H.264 | ≤960p | 30 fps | MIC |
| SN9C5256AJG | onsemi (Aptina) | AR0135 | YUY2 / MJPG | ≤720p | 30 fps | Global shutter |
| SN9C5259AFG | onsemi (Aptina) | AR0144 | YUY2 / MJPG | ≤720p (≈0.9 MP) | 30 fps | Global shutter |
| SN9C292BIG | onsemi (Aptina) | AR0144 | YUY2/MJPG/H.264 | ≤720p | 30 fps | — |
| 2089D (with MIC) | onsemi (Aptina) | AR0144CS | RAW / MIPI | 1 MP | — | — |
| 2089B (sync, no MIC) | onsemi (Aptina) | AR0144CS | RAW / MIPI | 1 MP | 30 fps | — |
| SN9C2902S/M | onsemi (Aptina) | AR0230 | YUY2 / MJPG | ≤1080p | 30 fps | MIC; 3D-NR |
| SN9C2279S | onsemi (Aptina) | AR0230 | YUY2 / MJPG | ≤1080p | 30 fps | MIC; Digital HDR; vertical distortion correction |
| SN9C2272M | onsemi (Aptina) | AR0230 | YUY2 / MJPG | ≤1080p | 30 fps | Digital HDR; vertical distortion correction |
| SN9C2285A | onsemi (Aptina) | AR0230 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| SN9C5256AJG | onsemi (Aptina) | AR0230 | YUY2 / MJPG | ≤1080p | 30 fps | HDR |
| SN9C292BIG | onsemi (Aptina) | AR0230 | YUY2/MJPG/H.264 | ≤1080p | 30 fps | HDR; MIC |
| 2092C | onsemi (Aptina) | AR0230 | RAW / DVP | 2 MP | — | HDR/wide dynamic |
| SN9C2805AJG | onsemi (Aptina) | AR0234 | YUY2 / MJPG | ≤1080p | 60 fps | Global shutter |
| SN9C292BIG | onsemi (Aptina) | AR0234 | YUY2/MJPG | ≤1080p | 30 fps | Global shutter; MIC |
| 7500A (with MIC) | onsemi (Aptina) | AR0234 | RAW / MIPI | 2 MP | — | 1920×1080@90; 1280×720@160; 1920×1080@120; 1920×1200@110 |
| 2630A (USB3.0, with MIC) | onsemi (Aptina) | AR0234 | RAW / MIPI | 2 MP | 60 fps | — |
| SN9C2279S | onsemi (Aptina) | AR0237 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| SN9C5256AJG | onsemi (Aptina) | AR0237 | YUY2 / MJPG | ≤1080p | 30 fps | — |
| SN9C2272M | onsemi (Aptina) | AR0246 | YUY2 / MJPG | ≤1080p | 30 fps | Digital HDR; vertical distortion correction |
| SN9C2272M | onsemi (Aptina) | AR0330 | YUY2 / MJPG | ≤3 MP | 30 fps | Digital HDR; vertical distortion correction |
| SN9C292BIG | onsemi (Aptina) | AR0330 | YUY2/MJPG/H.264 | ≤1080p | 30 fps | MIC |
| SN9C2805AJG | onsemi (Aptina) | AR0331 | YUY2 / MJPG | ≤3 MP | 20 fps | — |
| SN9C2279S | onsemi (Aptina) | AR0331 | YUY2 / MJPG | ≤1080p | 25 fps | MIC |
| SN9C2272M | onsemi (Aptina) | AR0331 | YUY2 / MJPG | ≤3 MP | 25 fps | Digital HDR; vertical distortion correction |
| SN9C2285A | onsemi (Aptina) | AR0331 | YUY2 / MJPG | ≤3 MP | 30 fps | WDR |
| SN9C292BIG | onsemi (Aptina) | AR0331 | YUY2/MJPG/H.264 | ≤1080p | 30 fps | HDR; MIC |
| SN9C5259AFG | onsemi (Aptina) | AR0521 | YUY2 / MJPG | ≤5 MP | 25 fps | MIC |
| SN9C2809E | onsemi (Aptina) | AR0821 | YUY2 / MJPG | ≤4K (≈8.3 MP) | 30 fps | MIC |
| SN9C2730JG / SN9C2720M | BF | BF2013 | YUY2 / MJPG | ≤VGA | 30 fps | Narrow-bezel NB |
| SN9C263A | BYD | BF2013 | YUY2 | ≤VGA | 30 fps | — |
| 2282B (RS-485) | BYD | BF2013 | RAW / DVP | VGA | — | Serial (RS-485) |
| 2072A | BYD | BF2013 | RAW/YUV (DVP) | VGA | — | — |
| 2072A | BYD | BF20A1 | RAW (MIPI) | VGA | — | — |
| 2050A | BYD | BF20A6 | YUV (DVP) | VGA (≈0.3 MP) | — | — |
| 2072A | BYD | BF20A6 | YUV / DVP | VGA | — | — |
| CH9004/CH9005/CH9010 | BYD | BF20A6 | YUV / DVP | 0.3 MP | 480p 30fps | — |
| SN9C2285A | — (BF) | BF2206 | YUY2 / MJPG | ≤2 MP | 15 fps | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | BYD | BF2257 | RAW / MIPI | 2 MP | — | Max resolution: 1600×1200 |
| CH9004/CH9005/CH9009 | BYD | BF2503 | YUV / DVP | 0.3 MP | 480p 30fps | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | BYD | BF3016 | RAW / DVP | 2 MP | — | — |
| CH9004/CH9005/CH9007 | BYD | BF3067 | YUV / DVP | 0.3 MP | 480p 30fps | — |
| 2050A | BYD | BF30A2 | YUV (SPI) | VGA (≈0.3 MP) | — | — |
| SN9C2726S/M | BYD | BF314A | YUY2/MJPG | ≤720p | 30 fps | — |
| SN9C2730JG / SN9C2720M | BF | BF314A | YUY2 / MJPG | ≤720p | 30 fps | — |
| 2075A / 2085A / 2087S (narrow-bezel) | BYD | BF314A | RAW / MIPI | 1 MP | 60 fps | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | BYD | BF314A | RAW / MIPI | 1 MP | — | — |
| SN9C2279S | BYD | BF3238CS | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | BYD | BF3238CS | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | BYD | BF3238CS | RAW / MIPI | 2 MP | — | — |
| SN9C263A | BYD | BF3703 | YUY2 | ≤VGA | 30 fps | — |
| 2072A | BYD | BF3703 | YUV / DVP | VGA | — | — |
| CH9004/CH9005/CH9008 | BYD | BF3703 | YUV / DVP | 0.3 MP | 480p 30fps | — |
| 2072A | BYD | BF3903 | YUV / DVP | VGA | — | — |
| CH9004/CH9005/CH9011 | BYD | BF3903 | YUV / DVP | 0.3 MP | 480p 30fps | — |
| CH9004/CH9005/CH9032 | BYD | BF3925 | YUV / DVP | 2 MP | 480p 30fps; 720p 10fps; 1200p 5fps | — |
| SN9C7601 | BYD | BF3A03 | Analog | ≤VGA | 30 fps | — |
| 2072A | BYD | BF3A03 | YUV (DVP) | VGA | — | — |
| CH9004/CH9005/CH9006 | BYD | BF3A03 | YUV / DVP | 0.3 MP (VGA) | 480p 30fps | — |
| 2075A / 2085A / 2087S (narrow-bezel) | BG0703 | RAW / MIPI | ~0.7–1 MP | — | — | |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | BG series | BG0703 | RAW / MIPI | 2 MP | — | — |
| 2092C | BG series | BG0806 | RAW / MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | BG series | BG0806 | RAW / DVP·MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | BG series | BG0808 | RAW / MIPI | 2 MP | — | — |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | BG series | BG0808 | RAW / MIPI | 2 MP | — | — |
| SN9C5256AJG | — (BG) | BG0836 | YUY2 / MJPG | ≤1080p | 30 fps | — |
| 2092C | BG series | BG0836 | RAW / DVP·MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | BG series | BG0836 | RAW / DVP·MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | BG series | BG0836 | RAW / DVP·MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | C2392 | RAW / MIPI | 2 MP | — | BSI | |
| SN9C269M | C2395 | YUY2 / MJPG | ≤1080p | 60 fps | — | |
| SN9C2279S | C2399 | YUY2 / MJPG | ≤1080p | 30 fps | MIC | |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | C2399 | RAW / MIPI | 2 MP | — | — | |
| SN9C2272M | C2496 | YUY2 / MJPG | ≤1080p | 30 fps | Digital HDR; vertical distortion correction | |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | C2496 | RAW / MIPI | 2 MP | — | BSI | |
| SN9C2805AJG | C3390 | YUY2 / MJPG | ≤3 MP | 30 fps | — | |
| SN9C2279S | C3390 | YUY2 / MJPG | ≤3 MP | 30 fps | MIC | |
| 2680A / 2680A1 (built-in digital mic, AF optional) | C8490 | RAW / MIPI | 8 MP | — | — | |
| SN9C291BIG | CP8210 | YUY2/MJPG/H.264 | ≤720p | 30 fps | HDR; MIC | |
| 2282B / 2093N (narrow-bezel, TNR) | CV2003 | RAW / MIPI | 2 MP | — | BSI | |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | CV2003 | RAW / MIPI | 2 MP | — | BSI | |
| SN9C269M | Brigates | ES101 | YUY2 / MJPG | 1000×1000 | 30 fps | — |
| SN9C2279S | Brigates | ES101 | YUY2 / MJPG | 960×960 | 60 fps | — |
| 2075A / 2085A / 2087S (narrow-bezel) | Brigates | ES101 | RAW / MIPI | 1 MP | — | Max still: 960×720 |
| 2076A / 2111 (narrow-bezel, TNR) | Brigates | ES101 | RAW / MIPI | 1 MP | — | Max still: 960×720 |
| 2282B / 2093N (narrow-bezel, TNR) | Brigates | ES101 | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | Brigates | ES101 | RAW / MIPI | 2 MP | — | — |
| 2650A (built-in digital mic; AF optional) | Brigates | ES101 | RAW / MIPI | 1 MP | 60 fps | Max res 960×960 |
| 2092C | SOI | F22 | RAW / DVP·MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | SOI | F22 | RAW / DVP·MIPI | 2 MP | — | — |
| 2092C | SOI | F23 | RAW / DVP·MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | SOI | F23 | RAW / DVP·MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | SOI | F25 | RAW / DVP·MIPI | 2 MP | — | — |
| 2092C | SOI | F28 | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | SOI | F28 | RAW / MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | SOI | F28 / F28P | RAW / MIPI | 2 MP | — | — |
| 2282B / 2093N (narrow-bezel, TNR) | SOI | F28P | RAW / MIPI | 2 MP | — | — |
| 2092C | SOI | F28P | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | SOI | F28P | RAW / MIPI | 2 MP | — | — |
| 2075A / 2085A / 2087S (narrow-bezel) | SOI | F37 | RAW / DVP | 1 MP | — | — |
| 2076A / 2111 (narrow-bezel, TNR) | SOI | F37 | RAW / MIPI | 1 MP | — | — |
| 2092C | SOI | F37 | RAW / MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | SOI | F37 | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | SOI | F37 | RAW / MIPI | 2 MP | — | — |
| 2282B / 2093N (narrow-bezel, TNR) | SOI | F37P | RAW / MIPI | 2 MP | — | — |
| 2092C | SOI | F37P | RAW / MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | SOI | F37P | RAW / MIPI | 2 MP | — | — |
| SN9C2730JG / SN9C2720M | FPX | FPX1002 | YUY2 / MJPG | ≤720p | 30 fps | — |
| CH9004/CH9005/CH9029 | GalaxyCore | GC0238C | YUV / DVP | 0.3 MP | 480p 30fps | — |
| SN9C2730JG / SN9C2720M | GalaxyCore | GC02M1 | YUY2 / MJPG | ≤720p | 30 fps | — |
| SN9C2272M | GalaxyCore | GC02M2 | YUY2 / MJPG | ≤2 MP | 30 fps | Digital HDR; vertical distortion correction |
| 2092C | GalaxyCore | GC02M2 | RAW / MIPI | 2 MP | 60 fps | Max still: 1600×1200; 800×600@60fps |
| 2075A / 2085A / 2087S (narrow-bezel) | GalaxyCore | GC02M2 / M1 | RAW / MIPI | 1 MP | — | — |
| 2076A / 2111 (narrow-bezel, TNR) | GalaxyCore | GC02M2 / M1 | RAW / MIPI | 1 MP | — | — |
| 2282B / 2093N (narrow-bezel, TNR) | GalaxyCore | GC02M2 / M1 | RAW / MIPI | 2 MP | — | Max still: 1600×1200 |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | GalaxyCore | GC02M2 / M1 | RAW / MIPI | 2 MP | — | Max still: 1600×1200 |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | GalaxyCore | GC02M2 / M1 | RAW / MIPI | 2 MP | — | Max res 1600×1200 |
| SN9C263AJG | GalaxyCore | GC0307 | YUY2 | ≤VGA | 30 fps | — |
| 2072A | GalaxyCore | GC0307 | YUV (DVP) | VGA | — | — |
| CH9004/CH9005/CH9025 | GalaxyCore | GC0307 | YUV / DVP | 0.3 MP | 480p 30fps | — |
| SN9C2726S/M | GalaxyCore | GC0308 | YUY2/MJPG | ≤VGA | 30 fps | — |
| SN9C259BFG | GalaxyCore | GC0308 | YUY2 | ≤VGA | 30 fps | Analog MIC |
| SN9C263A | GalaxyCore | GC0308 | YUY2 | ≤VGA | 30 fps | — |
| 2072A | GalaxyCore | GC0308 | RAW (DVP) | VGA | — | — |
| CH9004/CH9005/CH9027 | GalaxyCore | GC0308 | YUV / DVP | 0.3 MP | 480p 30fps | — |
| 2072A | GalaxyCore | GC0309 | YUV (DVP) | VGA | — | — |
| CH9004/CH9005/CH9026 | GalaxyCore | GC0309 | YUV / DVP | 0.3 MP | 480p 30fps | — |
| 2072A | GalaxyCore | GC030A | RAW / MIPI | VGA | — | — |
| 2075A / 2085A / 2087S (narrow-bezel) | GalaxyCore | GC030A | RAW / MIPI | VGA | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | GalaxyCore | GC030A | RAW / MIPI | VGA | — | — |
| 2072A | GalaxyCore | GC0311 | RAW/YUV / DVP | VGA | — | — |
| CH9004/CH9005/CH9028 | GalaxyCore | GC0311 | YUV / DVP | 0.3 MP | 480p 30fps | — |
| SN9C263AJG | GalaxyCore | GC0312 | YUY2 | ≤VGA | 30 fps | — |
| 2072A | GalaxyCore | GC0312 | YUV (DVP) | VGA | — | — |
| 2050A | GalaxyCore | GC0328 | YUV (DVP) | VGA (≈0.3 MP) | — | — |
| 2072A | GalaxyCore | GC0328 | RAW (DVP) | VGA | — | — |
| SN9C259BFG | GalaxyCore | GC0328C | YUY2 | ≤VGA | 30 fps | Analog MIC |
| SN9C263AJG | GalaxyCore | GC0328C | YUY2 | ≤VGA | 30 fps | — |
| 2050A | GalaxyCore | GC0329 | YUV (DVP) | VGA (≈0.3 MP) | — | — |
| CH9004/CH9005/CH9030 | GalaxyCore | GC0329 | YUV / DVP | 0.3 MP | 480p 30fps | — |
| SN9C263AJG | GalaxyCore | GC032A | YUY2 | ≤VGA | 30 fps | — |
| 2050A | GalaxyCore | GC032A | YUV (DVP) | VGA (≈0.3 MP) | — | — |
| CH9004/CH9005/CH9024 | GalaxyCore | GC032A | YUV / DVP | 0.3 MP | 480p 30fps | — |
| 2072A | GalaxyCore | GC033A | RAW / MIPI | VGA (≈0.3 MP) | — | — |
| 2120N | GalaxyCore | GC03A3 | RAW (MIPI) | 3 MP | Windows Hello | IR |
| 2150A2 | GalaxyCore | GC03A3 | RAW (MIPI) | 3 MP | Windows Hello | IR |
| SN9C2730JG / SN9C2720M | GalaxyCore | GC0403 | YUY2 / MJPG | ≤VGA | 30 fps | — |
| 2072A | GalaxyCore | GC0403 | RAW (MIPI) | VGA / 0.3–0.5 MP | — | — |
| 2075A / 2085A / 2087S (narrow-bezel) | GalaxyCore | GC0403 | RAW / MIPI | VGA | 60 fps | — |
| SN9C2730JG / SN9C2720M | GalaxyCore | GC0406 | YUY2 / MJPG | ≤VGA | 30 fps | — |
| 2072A | GalaxyCore | GC0406 / V06 | RAW (MIPI) | VGA | — | — |
| SN9C2805AJG | GalaxyCore | GC05A2 | YUY2 / MJPG | ≤5 MP | 30 fps | — |
| 2089D / 2150A2 (built-in digital mic; AF optional) | GalaxyCore | GC05A2 | RAW / MIPI | 5 MP | — | — |
| 7500A / 2089D2 narrow-bezel (built-in digital mic; AF optional) | GalaxyCore | GC05A2 | RAW / MIPI | 5 MP | — | — |
| 2072A | GalaxyCore | GC10?9* | RAW (DVP) | VGA | — | — |
| SN9C2759DM (3D-NR) | GalaxyCore | GC1009 | YUY2/MJPG | ≤720p | 30 fps | — |
| SN9C2730JG / SN9C2720M | GalaxyCore | GC1009 | YUY2 / MJPG | ≤720p | 30 fps | Narrow-bezel NB |
| 2089B (sync; no MIC) | GalaxyCore | GC1009 | RAW / MIPI | 1 MP | — | Dual-head |
| 2075A / 2085A / 2087S (narrow-bezel) | GalaxyCore | GC1009 | RAW / MIPI | 1 MP | — | — |
| 2076A / 2111 (narrow-bezel, TNR) | GalaxyCore | GC1009 | RAW / MIPI | 1 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | GalaxyCore | GC1009 | RAW / MIPI | 1 MP | — | — |
| SN9C291BIG | GalaxyCore | GC1024 | YUY2/MJPG/H.264 | ≤720p | 30 fps | MIC |
| 2089B (sync; no MIC) | GalaxyCore | GC1029 | RAW / MIPI | 1 MP | — | Dual-head |
| 2075A / 2085A / 2087S (narrow-bezel) | GalaxyCore | GC1029 | RAW / MIPI | 1 MP | — | — |
| 2076A / 2111 (narrow-bezel, TNR) | GalaxyCore | GC1029 | RAW / MIPI | 1 MP | — | — |
| 2650A (built-in digital mic; AF optional) | GalaxyCore | GC1029 | RAW / MIPI | 1 MP | — | — |
| 2075A / 2085A / 2087S (narrow-bezel) | GalaxyCore | GC1034 | RAW / MIPI | 1 MP | — | — |
| SN9C2726S/M | GalaxyCore | GC1054 | YUY2/MJPG | ≤720p | 30 fps | — |
| SN9C2730JG / SN9C2720M | GalaxyCore | GC1054 | YUY2 / MJPG | ≤720p | 30 fps | — |
| 2075A / 2085A / 2087S (narrow-bezel) | GalaxyCore | GC1054 | RAW / MIPI | 1 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | GalaxyCore | GC1054 | RAW / MIPI | 1 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | GalaxyCore | GC1054 | RAW / MIPI | 1 MP | — | — |
| SN9C291BIG | GalaxyCore | GC1064 | YUY2/MJPG/H.264 | ≤720p | 30 fps | MIC |
| SN9C2726S/M | GalaxyCore | GC1064 | YUY2/MJPG | ≤720p | 30 fps | — |
| 2075A / 2085A / 2087S (narrow-bezel) | GalaxyCore | GC1064 | RAW / MIPI | 1 MP | — | — |
| SN9C2730JG / SN9C2720M | GalaxyCore | GC1084 | YUY2 / MJPG | ≤720p | 30 fps | — |
| 2089B (sync; no MIC) | GalaxyCore | GC1084 | RAW / MIPI | 1 MP | — | Dual-head |
| 2075A / 2085A / 2087S (narrow-bezel) | GalaxyCore | GC1084 | RAW / MIPI | 1 MP | — | — |
| 2076A / 2111 (narrow-bezel, TNR) | GalaxyCore | GC1084 | RAW / MIPI | 1 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | GalaxyCore | GC1084 | RAW / MIPI | 1 MP | — | — |
| SN9C291BIG | GalaxyCore | GC1323 | YUY2/MJPG/H.264 | ≤720p | 30 fps | MIC |
| 2688A (built-in digital mic, AF optional) | GalaxyCore | GC13603P | RAW / MIPI | 13 MP class | — | — |
| SN9C2286 | GalaxyCore | GC13A0 | YUY2 / MJPG | ≤13 MP | 15 fps | |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | GalaxyCore | GC2033 | RAW / MIPI | 2 MP | — | — |
| 2075A / 2085A / 2087S (narrow-bezel) | GalaxyCore | GC2035 | RAW / MIPI | 1 MP | — | — |
| SN9C2895Q | GalaxyCore | GC2053 | YUY2 / MJPG | ≤1080p | 30 fps | RGB |
| SN9C2902S/M | GalaxyCore | GC2053 | YUY2 / MJPG | ≤1080p | 30 fps | MIC; 3D-NR |
| SN9C2279S | GalaxyCore | GC2053 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| SN9C2272M | GalaxyCore | GC2053 | YUY2 / MJPG | ≤1080p | 30 fps | Digital HDR; vertical distortion correction |
| SN9C2285A | GalaxyCore | GC2053 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| SN9C5256AJG | GalaxyCore | GC2053 | YUY2 / MJPG | ≤1080p | 30 fps | — |
| SN9C292BIG | GalaxyCore | GC2053 | YUY2/MJPG/H.264 | ≤1080p | 30 fps | MIC |
| 2688A (sync; MIC) | GalaxyCore | GC2053 | RAW / MIPI | 2 MP | — | Dual-head |
| 2282B (RS-485) | GalaxyCore | GC2053 | RAW / MIPI | 2 MP | — | Serial (RS-485) |
| 2076A / 2111 (narrow-bezel, TNR) | GalaxyCore | GC2053 | RAW / MIPI | 1 MP | — | — |
| 2282B / 2093N (narrow-bezel, TNR) | GalaxyCore | GC2053 | RAW / DVP·MIPI | 2 MP | — | — |
| 2092C | GalaxyCore | GC2053 | RAW / DVP·MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | GalaxyCore | GC2053 | RAW / DVP·MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | GalaxyCore | GC2053 | RAW / DVP·MIPI | 2 MP | — | Automotive-grade sensor |
| SN9C2902S/M | GalaxyCore | GC2083 | YUY2 / MJPG | ≤1080p | 30 fps | MIC; 3D-NR |
| SN9C2279S | GalaxyCore | GC2083 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| 2282B (RS-485) | GalaxyCore | GC2083 | RAW / MIPI | 2 MP | — | Serial (RS-485) |
| 2282B / 2093N (narrow-bezel, TNR) | GalaxyCore | GC2083 | RAW / MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | GalaxyCore | GC2083 | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | GalaxyCore | GC2083 | RAW / MIPI | 2 MP | — | — |
| SN9C2805AJG | GalaxyCore | GC2093 | YUY2 / MJPG | ≤1080p | 60 fps | — |
| SN9C2904SJG | GalaxyCore | GC2093 | YUY2 / MJPG | ≤1080p | 30 fps | MIC; HDR |
| SN9C292BIG | GalaxyCore | GC2093 | YUY2/MJPG/H.264 | ≤1080p | 30 fps | MIC |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | GalaxyCore | GC2093 | RAW / MIPI | 2 MP | — | — |
| 2089B | GalaxyCore | GC20A3T | RAW (MIPI) | 2 MP | Windows Hello | RGB |
| 2282B / 2093N (narrow-bezel, TNR) | GalaxyCore | GC20A3T | RAW / DVP·MIPI | 2 MP | — | — |
| 2092C | GalaxyCore | GC20A3T | RAW / DVP·MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | GalaxyCore | GC20A3T | RAW / DVP·MIPI | 2 MP | — | CRA 34.2° (chief-ray angle) |
| 2282B / 2093N (narrow-bezel, TNR) | GalaxyCore | GC20B03 | RAW / MIPI | 2 MP | — | — |
| SN9C2279S | GalaxyCore | GC2145 | YUY2 / MJPG | ≤2 MP | 20 fps | — |
| SN9C2272M | GalaxyCore | GC2145 | YUY2 / MJPG | ≤2 MP | 30 fps | Digital HDR; vertical distortion correction |
| SN9C263AJG | GalaxyCore | GC2145 | YUY2 | ≤2 MP | 5 fps | “VGA 30 fps” alt mode |
| 2092C | GalaxyCore | GC2145 | RAW / MIPI | 2 MP | — | Max still: 1600×1200 |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | GalaxyCore | GC2145 | RAW / MIPI | 2 MP | — | Max resolution: 1600×1200 |
| CH9004/CH9005/CH9034 | GalaxyCore | GC2145 | YUV / DVP | 2 MP | 480p 30fps; 720p 10fps; 1200p 5fps | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | GalaxyCore | GC235C | RAW / MIPI | 2 MP | — | Max resolution: 1600×1200 |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | GalaxyCore | GC235C | RAW / MIPI | 2 MP | — | Max res 1600×1200 |
| 2282B / 2093N (narrow-bezel, TNR) | GalaxyCore | GC2375 | RAW / MIPI | 2 MP | — | Max still: 1600×1200 |
| 2092C | GalaxyCore | GC2375 | RAW / MIPI | 2 MP | — | Max still: 1600×1200 |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | GalaxyCore | GC2375 | RAW / MIPI | 2 MP | — | Max resolution: 1600×1200 |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | GalaxyCore | GC2375 | RAW / MIPI | 2 MP | — | Max res 1600×1200 |
| 2075A / 2085A / 2087S (narrow-bezel) | GalaxyCore | GC2375H | RAW / MIPI | 1 MP | — | — |
| SN9C2272M | GalaxyCore | GC2385 | YUY2 / MJPG | ≤2 MP | 30 fps | Digital HDR; vertical distortion correction |
| 2282B / 2093N (narrow-bezel, TNR) | GalaxyCore | GC2385 | RAW / MIPI | 2 MP | — | Max still: 1600×1200 |
| 2092C | GalaxyCore | GC2385 | RAW / MIPI | 2 MP | — | Max still: 1600×1200 |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | GalaxyCore | GC2385 | RAW / MIPI | 2 MP | — | Max resolution: 1600×1200 |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | GalaxyCore | GC2385 | RAW / MIPI | 2 MP | — | Max res 1600×1200 |
| SN9C2895Q | GalaxyCore | GC2607 | YUY2 / MJPG | ≤1080p | 30 fps | RGB |
| SN9C269M | GalaxyCore | GC2607 | YUY2 / MJPG | ≤1080p | 30 fps | — |
| SN9C2272M | GalaxyCore | GC2607 | YUY2 / MJPG | ≤1080p | 30 fps | Digital HDR; vertical distortion correction |
| 2120N | GalaxyCore | GC2607 | RAW (MIPI) | 2 MP | Windows Hello | RGB |
| 2282B / 2093N (narrow-bezel, TNR) | GalaxyCore | GC2607 | RAW / MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | GalaxyCore | GC2607 | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | GalaxyCore | GC2607 | RAW / MIPI | 2 MP | — | — |
| 2282B / 2093N (narrow-bezel, TNR) | GalaxyCore | GC2755 | RAW / MIPI | 2 MP | — | — |
| 2092C | GalaxyCore | GC2755 | RAW / MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | GalaxyCore | GC2755 | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | GalaxyCore | GC2755 | RAW / MIPI | 2 MP | — | — |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | GalaxyCore | GC2755 | RAW / MIPI | 2 MP | — | — |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | GalaxyCore | GC4023 | RAW / MIPI | 3 MP | — | 720p 60 fps / VGA 120 fps |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | GalaxyCore | GC4633 | RAW / MIPI | 4 MP (used as 3 MP/2K) | — | — |
| SN9C2805AJG | GalaxyCore | GC4653 | YUY2 / MJPG | ≤2K (≈2 MP) | 30 fps | — |
| SN9C269M | GalaxyCore | GC4653 | YUY2 / MJPG | ≤2K | 30 fps | MIC |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | GalaxyCore | GC4653 | RAW / MIPI | 4 MP | — | — |
| SN9C5259AFG | GalaxyCore | GC4C33 | YUY2 / MJPG | ≤2K (≈2 MP) | 30 fps | — |
| SN9C2805AJG | GalaxyCore | GC4C33 | YUY2 / MJPG | ≤2K (≈2 MP) | 30 fps | — |
| 2089D / 2150A2 (built-in digital mic; AF optional) | GalaxyCore | GC5024 | RAW / MIPI | 5 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | GalaxyCore | GC5025 | RAW / MIPI | 2 MP (binned) | — | — |
| 2089D / 2150A2 (built-in digital mic; AF optional) | GalaxyCore | GC5025 | RAW / MIPI | 5 MP | — | — |
| SN9C2895Q | GalaxyCore | GC5035 | YUY2 / MJPG | ≤5 MP | 30 fps | RGB |
| SN9C2905RJG | GalaxyCore | GC5035 | YUY2 / MJPG | ≤5 MP | 30 fps | MIC; 3D-NR |
| SN9C2805AJG | GalaxyCore | GC5035 | YUY2 / MJPG | ≤5 MP | 30 fps | — |
| SN9C269M | GalaxyCore | GC5035 | YUY2 / MJPG | ≤5 MP | 25 fps | MIC |
| 2282B / 2093N (narrow-bezel, TNR) | GalaxyCore | GC5035 | RAW / MIPI | 2 MP (runs binned) | — | — |
| 2092C | GalaxyCore | GC5035 | RAW / MIPI | 2 MP (binned) | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | GalaxyCore | GC5035 | RAW / MIPI | 2 MP (binned) | — | note: legacy board claims 3 MP@25fps |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | GalaxyCore | GC5035 | RAW / MIPI | 2 MP (binned) | — | — |
| 2089D / 2150A2 (built-in digital mic; AF optional) | GalaxyCore | GC5035 | RAW / MIPI | 5 MP | — | — |
| SN9C2985S/R | GalaxyCore | GC5603 | YUY2 / MJPG | ≤5 MP | 30 fps | RGB; MIC |
| SN9C2905RJG | GalaxyCore | GC5603 | YUY2 / MJPG | ≤5 MP | 30 fps | MIC; 3D-NR |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | GalaxyCore | GC5652 / GC6603 | RAW / MIPI | 5 MP | — | BSI |
| SN9C2809E | GalaxyCore | GC8034 | YUY2 / MJPG | ≤8 MP | 30 fps | MIC |
| 2680A / 2680A1 (built-in digital mic, AF optional) | GalaxyCore | GC8034 | RAW / MIPI | 8 MP | — | — |
| 2680A / 2680A1 (built-in digital mic, AF optional) | GalaxyCore | GC8603 | RAW / MIPI | 8 MP | — | — |
| 2688A (built-in digital mic, AF optional) | GalaxyCore | GC8613 | RAW / MIPI | 4K pipeline | — | Supports 4K@30 |
| CH9004/CH9005/CH9033 | GalaxyCore | GT2005 | YUV / DVP | 2 MP | — | — |
| 2089B (sync; no MIC) | SOI | H62 | RAW / MIPI | 1 MP | — | Dual-head |
| 2075A / 2085A / 2087S (narrow-bezel) | SOI | H62 | RAW / MIPI | 1 MP | — | — |
| 2076A / 2111 (narrow-bezel, TNR) | SOI | H62 | RAW / MIPI | 1 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | SOI | H62 | RAW / MIPI | 1 MP | 60 fps | DVP 60 fps (note) |
| 2075A / 2085A / 2087S (narrow-bezel) | SOI | H63 | RAW / MIPI | 1 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | SOI | H63 | RAW / MIPI | 1 MP | 60 fps | — |
| 2075A / 2085A / 2087S (narrow-bezel) | SOI | H63P | RAW / MIPI | 1 MP | 60 fps | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | SOI | H63P | RAW / MIPI | 1 MP | — | — |
| 2089B (sync; no MIC) | SOI | H65 | RAW / MIPI | 1 MP | — | Dual-head |
| 2075A / 2085A / 2087S (narrow-bezel) | SOI | H65 | RAW / MIPI | 1 MP | — | — |
| 2076A / 2111 (narrow-bezel, TNR) | SOI | H65 | RAW / MIPI | 1 MP | — | — |
| 2075A / 2085A / 2087S (narrow-bezel) | SOI | H66 | RAW / MIPI | 1 MP | — | — |
| 2072A | — | H7375H | YUV (DVP) | VGA | — | — |
| SN9C2759DM (3D-NR) | — | HI-1A1 | YUY2/MJPG | ≤720p | 30 fps | — |
| 2075A / 2085A / 2087S (narrow-bezel) | Hynix | HI259 | RAW / MIPI | 1 MP | — | — |
| SN9C2895Q | Hynix | HI556 | YUY2 / MJPG | ≤5 MP | 30 fps | RGB |
| SN9C2905RJG | Hynix | HI556 | YUY2 / MJPG | ≤5 MP | 30 fps | MIC; 3D-NR |
| SN9C2730JG / SN9C2720M | Himax | HM03D5 | YUY2 / MJPG | ≤VGA | 30 fps | Endoscope |
| SN9C2730JG / SN9C2720M | Himax | HM1091 | YUY2 / MJPG | ≤720p | 30 fps | Narrow-bezel NB |
| 2075A / 2085A / 2087S (narrow-bezel) | Himax | HM1091 | RAW / MIPI | 1 MP | — | — |
| SN9C2895Q | Himax | HM1092 | YUY2 / MJPG | ≤720p | 30 fps | IR |
| SN9C2895Q | Himax | HM1092 | YUY2 / MJPG | ≤720p | 30 fps | IR |
| 2120N | Himax | HM1092 | RAW (MIPI) | 1 MP | Windows Hello | IR |
| 2089B | Himax | HM1092 | RAW (MIPI) | 1 MP | Windows Hello | IR |
| 7500A | Himax | HM1092 | RAW (MIPI) | 1 MP | Windows Hello | IR |
| SN9C2895Q | Himax | HM11B1 | YUY2 / MJPG | ≤720p | 30 fps | IR |
| CH9004/CH9005/CH9031 | Himax | HM1355 | YUV / DVP | 2 MP | 480p 30fps; 720p 10fps | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | Himax | HM2050 | RAW / DVP | 2 MP | — | Max resolution: 1600×1200 |
| CH9004/CH9005/CH9035 | Himax | HM2056 | YUV / DVP | 2 MP | 480p 30fps; 720p 10fps; 1200p 5fps | — |
| CH9004/CH9005/CH9036 | Himax | HM2057 | YUV / DVP | 2 MP | 480p 30fps; 720p 10fps; 1200p 5fps | — |
| CH9004/CH9005/CH9037 | Himax | HM2058 | YUV / DVP | 2 MP | 480p 30fps; 720p 10fps; 1200p 5fps | — |
| SN9C5256AJG | Himax | HM2131 | YUY2 / MJPG | ≤1080p | 30 fps | — |
| 2092C | Himax | HM2142 | RAW / MIPI | 2 MP | — | BSI |
| 2092C | Himax | HM2160 | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | Himax | HM2170 | RAW / MIPI | 2 MP | — | BSI |
| SN9C2904SJG | Himax | HM2172 | YUY2 / MJPG | ≤1080p | 30 fps | MIC; HDR |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | — | HT2029 | RAW / MIPI | 2 MP | — | — |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | Sony | IMX105 | RAW / MIPI | 2 MP | — | — |
| SN9C2279S | Sony | IMX132 | YUY2 / MJPG | ≤1080p | 30 fps | — |
| 2075A / 2085A / 2087S (narrow-bezel) | Sony | IMX132 | RAW / MIPI | 1 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | Sony | IMX132 | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | Sony | IMX132 | RAW / MIPI | 2 MP | — | — |
| 2680A / 2680A1 (built-in digital mic, AF optional) | Sony | IMX175 | RAW / MIPI | 8 MP | 15 fps | — |
| SN9C2809E | Sony | IMX179 | YUY2 / MJPG | ≤8 MP | 30 fps | MIC |
| SN9C5259AFG | Sony | IMX179 | YUY2 / MJPG | ≤8 MP | 15 fps | MIC, A3/AF |
| SN9C2808Z | Sony | IMX179 | YUY2 / MJPG | ≤8 MP | 15 fps | MIC |
| 2630A (USB3 normal) | Sony | IMX179 | RAW / MIPI | 8 MP | 20 fps | Digital zoom (in-SoC), optional AF |
| 2680A / 2680A1 (built-in digital mic, AF optional) | Sony | IMX179 | RAW / MIPI | 8 MP stills / UHD class | 15 fps | — |
| SN9C2759DM (3D-NR) | Sony | IMX188 | YUY2/MJPG | ≤720p | 30 fps | — |
| 2075A / 2085A / 2087S (narrow-bezel) | Sony | IMX190 | RAW / MIPI | 1 MP | — | — |
| SN9C5256AJG | Sony | IMX208 | YUY2 / MJPG | ≤1080p | 30 fps | — |
| SN9C2286 | Sony | IMX214 | YUY2 / MJPG | ≤13 MP | 15 fps | |
| 2688A (built-in digital mic, AF optional) | Sony | IMX214 | RAW / MIPI | 13 MP class | — | Supports 25 fps |
| SN9C5259AFG | Sony | IMX219 | YUY2 / MJPG | ≤8 MP | 15 fps | MIC |
| SN9C2808Z | Sony | IMX219 | YUY2 / MJPG | ≤8 MP | 15 fps | MIC |
| 2680A / 2680A1 (built-in digital mic, AF optional) | Sony | IMX219 | RAW / MIPI | 8 MP | — | — |
| SN9C291BIG | Sony | IMX225 | YUY2/MJPG/H.264 | ≤720p | 30 fps | MIC |
| YX9120AQG | Sony | IMX230 | YUY2 / MJPG | ≤21 MP | 20 fps | MIC |
| SN9C2286 | Sony | IMX258 | YUY2 / MJPG | ≤13 MP | 15 fps | |
| 2688A | Sony | IMX258 | RAW (MIPI) | up to 13 MP (4K+) | Windows Hello | RGB |
| 2630A (USB3 normal) | Sony | IMX258 | RAW / MIPI | up to 13 MP | 60 fps | Digital zoom (in-SoC), optional AF |
| 2688A (built-in digital mic, AF optional) | Sony | IMX258 | RAW / MIPI | 12 MP (interp.) | 15 fps | Supports 1080p 60 / 4K 30 |
| YX9113AQG | Sony | IMX260 | YUY2 / MJPG | ≤12 MP | 20 fps | MIC |
| 2688A (built-in digital mic, AF optional) | Sony | IMX278 | RAW / MIPI | 12 MP (interp.) | — | Supports 4K 30 |
| SN9C292BIG | Sony | IMX291 | YUY2/MJPG/H.264 | ≤1080p | 30 fps | Night vision; MIC |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | Sony | IMX291 | RAW / MIPI | 2 MP | — | — |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | Sony | IMX291 | RAW / MIPI | 2 MP | — | Max res 1920×1080 |
| YX9120AQG | Sony | IMX298 | YUY2 / MJPG | ≤16 MP | 20 fps | MIC |
| SN9C2286 | Sony | IMX298 | YUY2 / MJPG | ≤16 MP | 10 fps | MIC |
| 2688A (built-in digital mic, AF optional) | Sony | IMX298 | RAW / MIPI | 11 MP (interp.) | — | — |
| SN9C2279S | Sony | IMX307 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| SN9C2272M | Sony | IMX307 | YUY2 / MJPG | ≤1080p | 30 fps | Digital HDR; vertical distortion correction |
| SN9C2285A | Sony | IMX307 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | Sony | IMX307 | RAW / MIPI | 2 MP | — | — |
| SN9C2809E | Sony | IMX317 | YUY2 / MJPG | ≤4K (≈8.3 MP) | 30 fps | MIC |
| 2688A (built-in digital mic, AF optional) | Sony | IMX317 | RAW / MIPI | 4K video | — | Supports 1080p @ 60 |
| SN9C5259AFG | Sony | IMX319 | YUY2 / MJPG | ≤8 MP | 15 fps | MIC |
| SN9C2808Z | Sony | IMX319 | YUY2 / MJPG | ≤8 MP | 15 fps | MIC |
| SN9C5256AJG | Sony | IMX323 | YUY2 / MJPG | ≤1080p | 30 fps | — |
| SN9C292BIG | Sony | IMX323 | YUY2/MJPG/H.264 | ≤1080p | 30 fps | MIC |
| SN9C2805AJG | Sony | IMX327 | YUY2 / MJPG | ≤1080p | 60 fps | — |
| SN9C269M | Sony | IMX327 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| 2688A (built-in digital mic, AF optional) | Sony | IMX334 | RAW / MIPI | 4K video | 15 fps | Supports 4K@30 |
| SN9C2905RJG | Sony | IMX335 | YUY2 / MJPG | ≤5 MP | 30 fps | MIC; 3D-NR |
| 2650A (built-in digital mic; AF optional) | Sony | IMX335 | RAW / MIPI | 5 MP | — | — |
| 2089D / 2150A2 (built-in digital mic; AF optional) | Sony | IMX355 | RAW / MIPI | 12 MP (binned) | — | — |
| YX9113AQG | Sony | IMX362 | YUY2 / MJPG | ≤12 MP | 20 fps | MIC |
| SN9C2286 | Sony | IMX362 | YUY2 / MJPG | ≤12 MP | 15 fps | |
| SN9C2809E | Sony | IMX362 | YUY2 / MJPG | ≤4K (≈8.3 MP) | 30 fps | MIC |
| 2688A | Sony | IMX362 | RAW (MIPI) | up to 12 MP (4K) | Windows Hello | RGB |
| 2688A (built-in digital mic, AF optional) | Sony | IMX362 | RAW / MIPI | 2K video class | 60 fps | — |
| 2688A (built-in digital mic, AF optional) | Sony | IMX362/363 | RAW / MIPI | 12 MP / 4K pipeline | — | Supports 4K@30 |
| SN9C2905RJG | Sony | IMX376 | YUY2 / MJPG | ≤5 MP | 30 fps | MIC; 3D-NR |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | Sony | IMX376 | RAW / MIPI | 4 MP | — | — |
| SN9C2286 | Sony | IMX377 | YUY2 / MJPG | ≤12 MP | 15 fps | |
| SN9C2809E | Sony | IMX377 | YUY2 / MJPG | ≤4K (≈8.3 MP) | 30 fps | MIC |
| 2688A (built-in digital mic, AF optional) | Sony | IMX377 | RAW / MIPI | 12 MP class | — | Supports 30 fps |
| 2688A (built-in digital mic, AF optional) | Sony | IMX378 | RAW / MIPI | 12 MP class | — | Supports 30 fps |
| 7500A / 2089D2 narrow-bezel (built-in digital mic; AF optional) | Sony | IMX380 | RAW / MIPI | ~12 MP (used binned) | — | — |
| 2688A (built-in digital mic, AF optional) | Sony | IMX380 | RAW / MIPI | ~12 MP class | — | Supports 30 fps |
| SN9C2805AJG | Sony | IMX385 | YUY2 / MJPG | ≤1080p | 30 fps | Starlight |
| SN9C269M | Sony | IMX385 | YUY2 / MJPG | ≤1080p | 30 fps | Starlight |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | Sony | IMX385 | RAW / MIPI | 1 MP | — | — |
| 2650A (built-in digital mic; AF optional) | Sony | IMX385 | RAW / MIPI | 2 MP | 60 fps | Max res 1920×1080 |
| YX9113AQG | Sony | IMX415 | YUY2 / MJPG | ≤4K (≈8.3 MP) | 30 fps | MIC |
| SN9C2809E | Sony | IMX415 | YUY2 / MJPG | ≤4K (≈8.3 MP) | 30 fps | MIC |
| 2688A (built-in digital mic, AF optional) | Sony | IMX415 | RAW / MIPI | 4K video | — | — |
| 2688A (built-in digital mic, AF optional) | Sony | IMX458 | RAW / MIPI | 12 MP (interp.) | — | Supports 1080p 60 / 4K 30 |
| SN9C2279S | Sony | IMX486 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| 2688A (built-in digital mic, AF optional) | Sony | IMX486 | RAW / MIPI | ~8–13 MP class | — | — |
| SN9C2885 | Sony | IMX488 | YUY2 / MJPG | ≤720p | 30 fps | RGB-IR |
| 2688A (built-in digital mic, AF optional) | Sony | IMX577 | RAW / MIPI | 12 MP class | — | Supports 30 fps |
| SN9C2808Z | Sony | IMX582 | YUY2 / MJPG | ≤8 MP | 15 fps | MIC |
| 2688A (built-in digital mic, AF optional) | Sony | IMX582 | RAW / MIPI | 4K pipeline | 24 fps | Supports 4K@30 |
| YX9148AQG | Sony | IMX586 | YUY2 / MJPG | ≤48 MP | 15 fps | MIC |
| 2688A (built-in digital mic, AF optional) | Sony | IMX586 | RAW / MIPI | 4K pipeline | 21 fps | Supports 4K@30 |
| 2688A (built-in digital mic, AF optional) | Sony | IMX598 | RAW / MIPI | 4K pipeline | 24 fps | Supports 4K@28 |
| YX9148AQG | Sony | IMX766 | YUY2 / MJPG | ≤48 MP | 15 fps | MIC |
| SN9C2286 | Sony | IMX766 | YUY2 / MJPG | ≤13 MP | 15 fps | |
| 2688A (built-in digital mic, AF optional) | Sony | IMX766 | RAW / MIPI | 4K video | 15 fps | Supports 4K@30 |
| SN9C2805AJG | SOI | JX-F22 | YUY2 / MJPG | ≤1080p | 60 fps | — |
| SN9C269M | SOI | JX-F23 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| SN9C2285A | SOI | JX-F23 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| SN9C5256AJG | SOI | JX-F23 | YUY2 / MJPG | ≤1080p | 30 fps | — |
| SN9C269M | SOI | JX-F35 | YUY2 / MJPG | ≤1080p | 60 fps | MIC |
| SN9C2279S | SOI | JX-F37 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| SN9C2272M | SOI | JX-F37 | YUY2 / MJPG | ≤1080p | 30 fps | Digital HDR; vertical distortion correction |
| SN9C2730JG / SN9C2720M | SOI | JX-H61P | YUY2/MJPG | ≤720p | 30 fps | DVP |
| SN9C291BIG | SOI | JX-H65 | YUY2/MJPG/H.264 | ≤960p | 30 fps | MIC |
| SN9C2285A | SOI | JX-H68 | YUY2 / MJPG | ≤960p | 30 fps | — |
| SN9C2726S/M | SOI | JX-H68 | YUY2/MJPG | ≤720p | 30 fps | — |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | SOI | JXK03 | RAW / DVP·MIPI | 3 MP | — | — |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | SOI | JXK05 | RAW / MIPI | 3 MP | — | — |
| 2072A | SOI | JX-V01 | RAW (MIPI) | VGA | — | — |
| 2072A | — | K82 | RAW (DVP) | VGA | — | — |
| SN9C259BFG | MicroImage | MI2010 | YUY2 / MJPG | ≤2 MP | 15 fps | Analog MIC |
| SN9C5259AFG | onsemi (Aptina) | MI5100 | YUY2 / MJPG | ≤5 MP | 15 fps | MIC |
| SN9C2279S | onsemi (Aptina) | MIS2006 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| SN9C2279S | onsemi (Aptina) | MIS2006 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| SN9C2805AJG | onsemi (Aptina) | MIS5001 | YUY2 / MJPG | ≤5 MP | 30 fps | — |
| 2680A / 2680A1 (built-in digital mic, AF optional) | onsemi (Aptina) | MT811 | RAW / MIPI | 8 MP | — | — |
| SN9C2286 | onsemi (Aptina) | MT9J003 | YUY2 / MJPG | ≤10 MP | 15 fps | |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | onsemi (Aptina) | MT9M001 | RAW / MIPI | 2 MP | — | — |
| 2075A / 2085A / 2087S (narrow-bezel) | onsemi (Aptina) | MT9M114 | RAW / DVP | 1 MP | — | — |
| SN9C291BIG | — | N3 | YUY2/MJPG/H.264 | ≤720p | 30 fps | RX; MIC |
| SN9C292BIG | — | N3 | YUY2/MJPG/H.264 | ≤1080p | 25/30 fps | RX |
| SN9C259BFG | Novatek | NT99141 | YUY2/MJPG | ≤720p | 30 fps | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | Novatek | NT99231 | RAW / MIPI | 2 MP | — | — |
| SN9C2805AJG | Novatek | NT99235A | YUY2 / MJPG | ≤1080p | 60 fps | HDR |
| 2282B / 2093N (narrow-bezel, TNR) | OmniVision | OC0TB1B | RAW / MIPI | 2 MP | 120 fps | Max still: 400×400 |
| 7500A (USB2, medical) | OmniVision | OCH2B10 + 428 | RAW / MIPI | up to 1488×1488 | 60 fps | Medical endoscope |
| 2630A (USB3, medical) | OmniVision | OCH2B10 + 428 | RAW / MIPI | up to 1504×1504 | — | Medical endoscope |
| 2630A (USB3 normal) | OmniVision | OCH2B10+428 | RAW / MIPI | 4 MP | — | Digital zoom (in-SoC), optional AF |
| 2650A (built-in digital mic; AF optional) | OmniVision | OCH2B10+428 | RAW / MIPI | ~2 MP | — | Max res 1504×1504 |
| 7500A (USB2, medical) | OmniVision | OCHFA10 + 428 | RAW / MIPI | up to 720×720 | — | Medical endoscope |
| 2630A (USB3, medical) | OmniVision | OCHFA10 + 428 | RAW / MIPI | up to 720×720 | — | Medical endoscope |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | OmniVision | OCHSA10 | RAW / MIPI | ~1 MP | 60 fps | Max res 800×800 |
| 2282B (USB2, medical) | OmniVision | OCHTA10 + 426 | RAW / DVP | up to 400×392 | — | Medical endoscope |
| 2089D2 (with MIC + TNR) | OmniVision | OG02B10 | RAW / MIPI | 2 MP | 60 fps | 1600×1300 @60; 1280×720 @90 |
| 2630A (USB3.0, with MIC) | OmniVision | OG02B10 | RAW / MIPI | 2 MP | 60 fps | 1600×1300 |
| SN9C2805AJG | OmniVision | OG02B1B | YUY2 / MJPG | ≤1600×1200 | 60 fps | Global shutter |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | OmniVision | OH01A10 | RAW / MIPI | 1 MP | 60 fps | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | OmniVision | OH01A10 | RAW / MIPI | ~1 MP | 60 fps | Max res 1280×720 |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | OmniVision | OH01A10 | RAW / MIPI | ~1 MP | 60 fps | — |
| 2650A (built-in digital mic; AF optional) | OmniVision | OH01A10 | RAW / MIPI | ~1 MP | — | — |
| 2688A (built-in digital mic, AF optional) | onsemi | OH0840 | RAW / MIPI | 8 MP / 4K pipeline | — | — |
| SN9C2279S | OmniVision | OS02C10 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| 2075A / 2085A / 2087S (narrow-bezel) | OmniVision / SuperPix | OS02D10 / SP2329 | RAW / MIPI | 1 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OS02F10 | RAW / MIPI | 2 MP | — | — |
| SN9C2279S | OmniVision | OS02G10 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OS02G10 | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | OmniVision | OS02G10 | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | OmniVision | OS02H10 | RAW / MIPI | 2 MP | — | — |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | OmniVision | OS02H10 | RAW / MIPI | 2 MP | 60 fps | — |
| SN9C2279S | OmniVision | OS02K10 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| SN9C2272M | OmniVision | OS02K10 | YUY2 / MJPG | ≤1080p | 30 fps | Digital HDR; vertical distortion correction |
| SN9C2285A | OmniVision | OS02K10 | YUY2 / MJPG | ≤1080p | 30 fps | MIC; MIPI-out only; digital HDR; vertical-distortion correction |
| 2630A (USB3 normal) | OmniVision | OS02K10 | RAW / MIPI | 2 MP | 60 fps | Digital zoom (in-SoC), optional AF |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OS02N10 | RAW / MIPI | 2 MP | — | — |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | OmniVision | OS04C10 | RAW / MIPI | 4 MP | — | Resolution 2688×1520 |
| SN9C5259AFG | OmniVision | OS05A10 | YUY2 / MJPG | ≤5 MP | 25 fps | MIC |
| SN9C2905RJG | OmniVision | OS05A10 | YUY2 / MJPG | ≤5 MP | 30 fps | MIC; 3D-NR |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | OmniVision | OS05A20 | RAW / MIPI | 5 MP | — | — |
| SN9C2809E | OmniVision | OS08A10 | YUY2 / MJPG | ≤4K (≈8.3 MP) | 30 fps | MIC |
| 2688A (built-in digital mic, AF optional) | OmniVision | OS08A20 | RAW / MIPI | 8 MP / 4K pipeline | — | — |
| SN9C2885 | OmniVision | OV01A1S | YUY2 / MJPG | ≤720p | 30 fps | RGB-IR |
| 2072A | OmniVision | OV02B10 | RAW (MIPI) | 2 MP | — | — |
| 2282B / 2093N (narrow-bezel, TNR) | OmniVision | OV02B10 | RAW / MIPI | 2 MP | — | Max still: 1600×1200 |
| SN9C2895Q | OmniVision | OV02C10 | YUY2 / MJPG | ≤1080p | 30 fps | RGB |
| SN9C269M | OmniVision | OV02C10 | YUY2 / MJPG | ≤1080p | 30 fps | — |
| SN9C2272M | OmniVision | OV02C10 | YUY2 / MJPG | ≤1080p | 30 fps | Digital HDR; vertical distortion correction |
| 2120N | OmniVision | OV02C10 | RAW (MIPI) | 2 MP | Windows Hello | RGB |
| 2089B (sync; no MIC) | OmniVision | OV02C10 | RAW / MIPI | 2 MP | — | Dual-head |
| 2688A (sync; MIC) | OmniVision | OV02C10 | RAW / MIPI | 2 MP | — | Dual-head |
| 2282B / 2093N (narrow-bezel, TNR) | OmniVision | OV02C10 | RAW / MIPI | 2 MP | — | — |
| 2092C | OmniVision | OV02C10 | RAW / MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV02C10 | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | OmniVision | OV02C10 | RAW / MIPI | 2 MP | — | — |
| 2089D / 2150A2 (built-in digital mic; AF optional) | OmniVision | OV02C10 | RAW / MIPI | 2 MP | 60 fps | — |
| 2650A (built-in digital mic; AF optional) | OmniVision | OV02C10 | RAW / MIPI | 2 MP | 60 fps | — |
| 7500A (with MIC) | OmniVision | OV05B1B | RAW / MIPI | 5 MP | — | Monochrome; 2592×1944 @30 |
| 2688A (with MIC) | OmniVision | OV05B1B | RAW / MIPI | 5 MP | — | Mono; 2592×1944@48 |
| 7500A / 2089D2 narrow-bezel (built-in digital mic; AF optional) | OmniVision | OV05B1B / 1S | RAW / MIPI | 5 MP | — | — |
| 7500A (with MIC) | OmniVision | OV05B1S | RAW / MIPI | 5 MP | — | Color |
| 2688A (with MIC) | OmniVision | OV05B1S | RAW / MIPI | 5 MP | — | Color; 1280×720@120 |
| SN9C2805AJG | OmniVision | OV05C10 | YUY2 / MJPG | ≤5 MP | 30 fps | — |
| 7500A / 2089D2 narrow-bezel (built-in digital mic; AF optional) | OmniVision | OV05C10 | RAW / MIPI | 5 MP | — | — |
| 2680A / 2680A1 (built-in digital mic, AF optional) | OmniVision | OV08A10 | RAW / MIPI | 8 MP | 1080p 60, 720p 90 | |
| SN9C2730JG / SN9C2720M | OmniVision | OV10635 | YUY2/MJPG | ≤960p | 30 fps | WDR |
| 2688A (built-in digital mic, AF optional) | OmniVision | OV12890 | RAW / MIPI | 12 MP / 4K pipeline | — | Supports 4K@30 |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV13B10 | RAW / MIPI | 2 MP (binned) | — | 1/3.06″, 1.12 µm |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | OmniVision | OV13B10 | RAW / MIPI | 13 MP (used binned) | — | — |
| 2688A (built-in digital mic, AF optional) | OmniVision | OV13B10 | RAW / MIPI | 13 MP class | — | — |
| SN9C2286 | OmniVision | OV16860 | YUY2 / MJPG | ≤16 MP | 10 fps | MIC |
| CH9004/CH9005/CH9014 | OmniVision | OV2640 | YUV / DVP | 0.3 MP (VGA mode) | 480p 30fps | — |
| SN9C259BFG | OmniVision | OV2643 | YUY2 | ≤2 MP | 15 fps | Analog MIC |
| SN9C263AJG | OmniVision | OV2659 | YUY2 | ≤VGA | 30 fps | — |
| CH9004/CH9005/CH9016 | OmniVision | OV2659 | YUV / DVP | 0.3 MP | 480p 30fps | — |
| 2282B / 2093N (narrow-bezel, TNR) | OmniVision | OV2680 | RAW / MIPI | 2 MP | — | Max still: 1600×1200 |
| 2092C | OmniVision | OV2680 | RAW / MIPI | 2 MP | — | Max still: 1600×1200 |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV2680 | RAW / MIPI | 2 MP | — | 1/5″, 1.75 µm |
| SN9C2730JG / SN9C2720M | OmniVision | OV2685 | YUY2 / MJPG | ≤720p | 30 fps | — |
| SN9C2279S | OmniVision | OV2710 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| SN9C5256AJG | OmniVision | OV2710 | YUY2 / MJPG | ≤1080p | 30 fps | 720p@60; VGA@120 |
| SN9C292BIG | OmniVision | OV2710 | YUY2/MJPG/H.264 | ≤1080p | 30 fps | MIC |
| 2075A / 2085A / 2087S (narrow-bezel) | OmniVision | OV2710 | RAW / MIPI | 1 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV2710 | RAW / MIPI | 2 MP | — | — |
| SN9C5256AJG | OmniVision | OV2718 | YUY2 / MJPG | ≤1080p | 30 fps | — |
| SN9C292BIG | OmniVision | OV2718 | YUY2/MJPG/H.264 | ≤1080p | 30 fps | MIC |
| SN9C2279S | OmniVision | OV2720 | YUY2 / MJPG | ≤1080p | 30 fps | — |
| SN9C2272M | OmniVision | OV2720 | YUY2 / MJPG | ≤1080p | 30 fps | Digital HDR; vertical distortion correction |
| 2282B / 2093N (narrow-bezel, TNR) | OmniVision | OV2720 | RAW / MIPI | 2 MP | — | — |
| 2075A / 2085A / 2087S (narrow-bezel) | OmniVision | OV2722 | RAW / MIPI | 1 MP | — | — |
| 2092C | OmniVision | OV2722 | RAW / MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV2722/20 | RAW / MIPI | 2 MP | — | — |
| 2092C | OmniVision | OV2724 | RAW / DVP·MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV2724 | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | OmniVision | OV2724 | RAW / MIPI | 2 MP | — | — |
| SN9C292BIG | OmniVision | OV2732 | YUY2/MJPG/H.264 | ≤1080p | 30 fps | — |
| SN9C2902S/M | OmniVision | OV2735 | YUY2 / MJPG | ≤1080p | 30 fps | MIC; 3D-NR |
| SN9C2279S | OmniVision | OV2735 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| SN9C2272M | OmniVision | OV2735 | YUY2 / MJPG | ≤1080p | 30 fps | Digital HDR; vertical distortion correction |
| SN9C2285A | OmniVision | OV2735 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| SN9C5256AJG | OmniVision | OV2735 | YUY2 / MJPG | ≤1080p | 30 fps | — |
| SN9C292BIG | OmniVision | OV2735 | YUY2/MJPG/H.264 | ≤1080p | 30 fps | — |
| 2630A (USB3 normal) | OmniVision | OV2735 | RAW / MIPI | 2 MP | — | Digital zoom (in-SoC), optional AF |
| 2075A / 2085A / 2087S (narrow-bezel) | OmniVision | OV2735 | RAW / MIPI | 1 MP | — | — |
| 2282B / 2093N (narrow-bezel, TNR) | OmniVision | OV2735 | RAW / MIPI | 2 MP | — | — |
| 2092C | OmniVision | OV2735 | RAW / MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV2735 | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | OmniVision | OV2735 | RAW / MIPI | 2 MP | — | — |
| SN9C2895Q | OmniVision | OV2740 | YUY2 / MJPG | ≤1080p | 30 fps | RGB |
| SN9C269M | OmniVision | OV2740 | YUY2 / MJPG | ≤1080p | 30 fps | — |
| SN9C2272M | OmniVision | OV2740 | YUY2 / MJPG | ≤1080p | 30 fps | Digital HDR; vertical distortion correction |
| 2089B (sync; no MIC) | OmniVision | OV2740 | RAW / MIPI | 1 MP | — | Dual 720p / single 1080p |
| 2282B / 2093N (narrow-bezel, TNR) | OmniVision | OV2740 | RAW / MIPI | 2 MP | — | — |
| 2092C | OmniVision | OV2740 | RAW / MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV2740 | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | OmniVision | OV2740 | RAW / MIPI | 2 MP | — | — |
| 2650A (built-in digital mic; AF optional) | OmniVision | OV2740 | RAW / MIPI | 2 MP | — | — |
| 2099N | OmniVision | OV2744 (COB) | RAW (MIPI) | 2 MP | Windows Hello | RGB+IR |
| SN9C259BFG | OmniVision | OV3660 | YUY2/MJPG | ≤1080p | 20 fps | — |
| SN9C2285A | OmniVision | OV426 + OV6946 | YUY2 / MJPG | ≤VGA | 30 fps | Endoscope |
| SN9C5259AFG | OmniVision | OV4689 | YUY2 / MJPG | ≤2K (≈2 MP) | 30 fps | — |
| SN9C2805AJG | OmniVision | OV4689 | YUY2 / MJPG | ≤2K (≈2 MP) | 30 fps | — |
| 2150A2 | OmniVision | OV4689 | RAW (MIPI) | 2 MP | Windows Hello | — |
| 7500A | OmniVision | OV4689 | RAW (MIPI) | 2 MP | Windows Hello | — |
| 2688A (sync; MIC) | OmniVision | OV4689 | RAW / MIPI | 2 MP | — | Dual-head sync |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | OmniVision | OV4689 | RAW / MIPI | 4 MP | 60 fps | — |
| 2650A (built-in digital mic; AF optional) | OmniVision | OV4689 | RAW / MIPI | 4 MP (used as 2 MP/1080p) | 120 fps | — |
| 2688A (built-in digital mic, AF optional) | OmniVision | OV4689 | RAW / MIPI | 2K video class | 60 fps | 2688×1520 @60; 1920×1080 @120 |
| SN9C5259AFG | OmniVision | OV5640 | YUY2 / MJPG | ≤5 MP | 15 fps | MIC |
| 2089D / 2150A2 (built-in digital mic; AF optional) | OmniVision | OV5640 | RAW / MIPI | 5 MP | — | — |
| SN9C269M | OmniVision | OV5643 | YUY2 / MJPG | ≤5 MP | 15 fps | MIC |
| SN9C2805AJG | OmniVision | OV5645 | YUY2 / MJPG | ≤5 MP | 30 fps | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV5645 | RAW / MIPI | 2 MP (binned) | — | — |
| 2089D / 2150A2 (built-in digital mic; AF optional) | OmniVision | OV5645 | RAW / MIPI | 5 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV5647 | RAW / MIPI | 2 MP (binned) | — | — |
| 2089D / 2150A2 (built-in digital mic; AF optional) | OmniVision | OV5647 | RAW / MIPI | 5 MP | — | — |
| SN9C2805AJG | OmniVision | OV5648 | YUY2 / MJPG | ≤5 MP | 15 fps | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV5648 | RAW / MIPI | 2 MP (binned) | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | OmniVision | OV5648 | RAW / MIPI | 2 MP (binned) | — | — |
| 2089D / 2150A2 (built-in digital mic; AF optional) | OmniVision | OV5648 | RAW / MIPI | 5 MP | 15 fps @ max res | — |
| SN9C2805AJG | OmniVision | OV5658 | YUY2 / MJPG | ≤5 MP | 30 fps | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV5670 | RAW / MIPI | 2 MP | — | 1/5″, 1.12 µm |
| SN9C2805AJG | OmniVision | OV5675 | YUY2 / MJPG | ≤5 MP | 30 fps | — |
| 2089D / 2150A2 (built-in digital mic; AF optional) | OmniVision | OV5675 | RAW / MIPI | 5 MP | 25 fps | — |
| 2650A (built-in digital mic; AF optional) | OmniVision | OV5675 | RAW / MIPI | 5 MP (binned) | 25 fps | — |
| SN9C2985S/R | OmniVision | OV5693 | YUY2 / MJPG | ≤5 MP | 30 fps | RGB; MIC |
| SN9C2905RJG | OmniVision | OV5693 | YUY2 / MJPG | ≤5 MP | 30 fps | MIC; 3D-NR |
| SN9C2805AJG | OmniVision | OV5693 | YUY2 / MJPG | ≤5 MP | 30 fps | — |
| 2150A2 | OmniVision | OV5693 | RAW (MIPI) | 5 MP | Windows Hello | RGB |
| 7500A | OmniVision | OV5693 | RAW (MIPI) | 5 MP | Windows Hello | RGB |
| 2630A (USB3 normal) | OmniVision | OV5693 | RAW / MIPI | 5 MP | 30 fps | Digital zoom (in-SoC), optional AF |
| 2282B / 2093N (narrow-bezel, TNR) | OmniVision | OV5693 | RAW / MIPI | 2 MP (used @ 1600×1200) | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV5693 | RAW / MIPI | 2 MP (binned) | — | — |
| 2089D / 2150A2 (built-in digital mic; AF optional) | OmniVision | OV5693 | RAW / MIPI | 5 MP | 1080p 60 fps (mode) | — |
| SN9C2805AJG | OmniVision | OV5695 | YUY2 / MJPG | ≤5 MP | 30 fps | also 1080p60 |
| 2150A2 | OmniVision | OV5695 | RAW (MIPI) | 5 MP | Windows Hello | RGB |
| 7500A | OmniVision | OV5695 | RAW (MIPI) | 5 MP | Windows Hello | RGB |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV5695 | RAW / MIPI | 2 MP (binned) | — | — |
| 2089D / 2150A2 (built-in digital mic; AF optional) | OmniVision | OV5695 | RAW / MIPI | 5 MP | 1080p 60 fps; 1600×1200 60 fps | — |
| 7500A / 2089D2 narrow-bezel (built-in digital mic; AF optional) | OmniVision | OV5695 | RAW / MIPI | 5 MP | — | — |
| 2092C (USB2, medical) | OmniVision | OV6946 + 426 | RAW / DVP | up to 400×400 | — | Medical endoscope |
| 2282B (USB2, medical) | OmniVision | OV6946 + 426 | RAW / DVP | up to 400×400 | — | Medical endoscope |
| SN9C5256AJG | OmniVision | OV7251 | YUY2/MJPG | ≤VGA | 30 fps | Iris recognition |
| SN9C2730JG / SN9C2720M | OmniVision | OV7251 | YUY2 / MJPG | ≤VGA | 100 fps | — |
| 2281D | OmniVision | OV7251 | RAW / MIPI | VGA | 120 fps | Monochrome |
| 2281B2 (with MIC) | OmniVision | OV7251 | RAW / MIPI | VGA | 110 fps | Monochrome |
| 2089B (sync, no MIC) | OmniVision | OV7251 | RAW / MIPI | VGA | 60 fps | — |
| 2072A | OmniVision | OV7676 | RAW (DVP) | VGA | — | — |
| CH9004/CH9005/CH9015 | OmniVision | OV7690 | YUV / DVP | 0.3 MP | 480p 30fps | — |
| 2072A | OmniVision | OV7692 | YUV / MIPI | VGA | — | — |
| SN9C259BFG | OmniVision | OV7725 | YUY2 | ≤VGA | 30 fps | Analog MIC |
| 2072A | OmniVision | OV7736 | RAW/YUV (DVP/MIPI) | VGA | — | — |
| SN9C259BFG | OmniVision | OV7740 | YUY2 | ≤VGA | 30 fps | — |
| SN9C7600 | OmniVision | OV7740 | Analog | ≤VGA | 30 fps | — |
| SN9C2805AJG | OmniVision | OV7750 | YUY2 / MJPG | ≤VGA | 120 fps | Global shutter |
| 2089D / 2150A2 (built-in digital mic; AF optional) | OmniVision | OV8825 | RAW / MIPI | 8 MP (used binned for 2K) | — | — |
| SN9C2808Z | OmniVision | OV8856 | YUY2 / MJPG | ≤8 MP | 15 fps | MIC |
| 2680A / 2680A1 (built-in digital mic, AF optional) | OmniVision | OV8856 | RAW / MIPI | 8 MP | — | — |
| 2680A / 2680A1 (built-in digital mic, AF optional) | OmniVision | OV8858 | RAW / MIPI | 8 MP | — | — |
| SN9C2805AJG | OmniVision | OV9281 | YUY2 / MJPG | ≤1280×800 | 120 fps | 640×400 @210 fps |
| SN9C269M | OmniVision | OV9281 | YUY2 / MJPG | ≤1280×800 | 120 fps | MIC; 640×360 @220 fps |
| SN9C2279S | OmniVision | OV9281 | YUY2 / MJPG | ≤720p | 60 fps | — |
| SN9C5256AJG | OmniVision | OV9281 | YUY2/MJPG | ≤1280×800 | 60 fps | Global shutter |
| 2281B2 (with MIC) | OmniVision | OV9281/OV9282 | RAW / MIPI | 1 MP | 120 fps | Mono; 640×400 @240 fps |
| 2089B (sync, no MIC) | OmniVision | OV9281/OV9282 | RAW / MIPI | 1 MP | 60 fps | — |
| 2630A (USB3.0, with MIC) | OmniVision | OV9281/OV9282 | RAW / MIPI | 1 MP | 120 fps | Monochrome |
| 2075A / 2085A / 2087S (narrow-bezel) | OmniVision | OV9660 | RAW / MIPI | 1 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV9712 | RAW / MIPI | 1 MP | — | — |
| 2075A / 2085A / 2087S (narrow-bezel) | OmniVision | OV9716 | RAW / MIPI | 1 MP | 60 fps | — |
| 2075A / 2085A / 2087S (narrow-bezel) | OmniVision | OV9726 | RAW / MIPI | 1 MP | — | — |
| SN9C2730JG / SN9C2720M | OmniVision | OV9728 | YUY2 / MJPG | ≤720p | 30 fps | — |
| 2075A / 2085A / 2087S (narrow-bezel) | OmniVision | OV9728 | RAW / MIPI | 1 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV9728 | RAW / MIPI | 2 MP | — | — |
| SN9C291BIG | OmniVision | OV9732 | YUY2/MJPG/H.264 | ≤720p | 30 fps | MIC |
| SN9C2726S/M | OmniVision | OV9732 | YUY2/MJPG | ≤720p | 30 fps | S version; MIC |
| SN9C2730JG / SN9C2720M | OmniVision | OV9732 | YUY2/MJPG | ≤720p | 30 fps | — |
| 2075A / 2085A / 2087S (narrow-bezel) | OmniVision | OV9732 | RAW / MIPI | 1 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV9732 | RAW / MIPI | 1 MP | — | — |
| SN9C292BIG | OmniVision | OV9734 | YUY2/MJPG/H.264 | ≤720p | 30 fps | — |
| SN9C2759DM (3D-NR) | OmniVision | OV9734 | YUY2/MJPG | ≤720p | 30 fps | — |
| SN9C2730JG / SN9C2720M | OmniVision | OV9734 | YUY2 / MJPG | ≤720p | 30 fps | Narrow-bezel NB |
| 2120N | OmniVision | OV9734 | RAW (MIPI) | 1 MP | Windows Hello | RGB |
| 2089B (sync; no MIC) | OmniVision | OV9734 | RAW / MIPI | 1 MP | — | Dual-head |
| 2075A / 2085A / 2087S (narrow-bezel) | OmniVision | OV9734 | RAW / MIPI | 1 MP | — | — |
| 2076A / 2111 (narrow-bezel, TNR) | OmniVision | OV9734 | RAW / MIPI | 1 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV9734 | RAW / MIPI | 1 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | OmniVision | OV9734 | RAW / MIPI | 1 MP | — | — |
| 2650A (built-in digital mic; AF optional) | OmniVision | OV9734 | RAW / MIPI | 1 MP | — | — |
| SN9C2885 | OmniVision | OV9738 | YUY2 / MJPG | ≤720p | 30 fps | RGB-IR |
| 2099N | OmniVision | OV9738 (COB) | RAW (MIPI) | 1 MP | Windows Hello | RGB+IR |
| 2075A / 2085A / 2087S (narrow-bezel) | OmniVision | OV9750 | RAW / MIPI | 1 MP | — | — |
| SN9C2730JG / SN9C2720M | OmniVision | OV9755 | YUY2/MJPG | ≤720p | 30 fps | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | OmniVision | OV9755 | RAW / MIPI | 1 MP | — | — |
| 2075A / 2085A / 2087S (narrow-bezel) | OmniVision | OV9760 | RAW / MIPI | 1 MP | — | — |
| 2089B (sync, no MIC) | OmniVision | OVM6211 | RAW / MIPI | — | 120 fps | — |
| SN9C292BIG | PixelPlus | PR2000K | YUY2/MJPG/H.264 | ≤720p | 30 fps | RX |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | PixelPlus | PS5230 | RAW / MIPI | 2 MP | — | — |
| 2092C | PixelPlus | PS5250 | RAW / DVP·MIPI | 2 MP | — | — |
| SN9C2272M | PixelPlus | PS5260 | YUY2 / MJPG | ≤1080p | 30 fps | Digital HDR; vertical distortion correction |
| SN9C2902S/M | PixelPlus | PS5268 | YUY2 / MJPG | ≤1080p | 30 fps | MIC; 3D-NR |
| SN9C2279S | PixelPlus | PS5268 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| SN9C2272M | PixelPlus | PS5268 | YUY2 / MJPG | ≤1080p | 30 fps | Digital HDR; vertical distortion correction |
| SN9C2285A | PixelPlus | PS5268 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| SN9C5256AJG | PixelPlus | PS5268 | YUY2 / MJPG | ≤1080p | 30 fps | HDR |
| SN9C292BIG | PixelPlus | PS5268 | YUY2/MJPG | ≤1080p | 30 fps | HDR; MIC |
| 2092C | PixelPlus | PS5268 | RAW / DVP | 2 MP | — | HDR/wide dynamic |
| 2281D / 2282B (TNR) | PixelPlus | PS5268 | RAW / DVP | 2 MP | — | VGA 60 fps |
| 2630A (USB3 HDR) | PixelPlus | PS5268 | RAW / MIPI | 2 MP | — | HDR/wide dynamic |
| SN9C2905RJG | PixelPlus | PS5520 | YUY2 / MJPG | ≤5 MP | 30 fps | HDR; MIC; 3D-NR |
| 2089D | PixelPlus | PS5520 | RAW / MIPI | 5 MP | — | HDR/wide dynamic |
| 2089D2 (TNR) | PixelPlus | PS5520 | RAW / MIPI | 5 MP | — | HDR/wide dynamic |
| 2630A (USB3 HDR) | PixelPlus | PS5520 | RAW / MIPI | 5 MP | — | HDR/wide dynamic |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | — | Q3P | RAW / MIPI | 3 MP | — | Resolution 2304×1296 |
| 2650A (with MIC) | — | S02 | RAW / MIPI | 1.3 MP | 180 fps | 1280×1024@180; 1280×720@250; 640×480@350; 1280×184@350; 1280×64@574 |
| SN9C5259AFG | Samsung | S5K3H7 | YUY2 / MJPG | ≤8 MP | 15 fps | MIC, AF |
| SN9C2808Z | Samsung | S5K3H7 | YUY2 / MJPG | ≤8 MP | 15 fps | MIC |
| SN9C2286 | Samsung | S5K3P9 | YUY2 / MJPG | ≤16 MP | 10 fps | MIC |
| SN9C5259AFG | Samsung | S5K4H7 | YUY2 / MJPG | ≤8 MP | 15 fps | MIC |
| 2680A / 2680A1 (built-in digital mic, AF optional) | Samsung | S5K4H7YX | RAW / MIPI | 8 MP | — | — |
| SN9C269M | Samsung | S5K5BA | YUY2 / MJPG | ≤5 MP | 15 fps | — |
| 2089D / 2150A2 (built-in digital mic; AF optional) | Samsung | S5K5E8YX | RAW / MIPI | 5 MP | — | — |
| 2075A / 2085A / 2087S (narrow-bezel) | Samsung | S5K6A1 | RAW / MIPI | 1 MP | — | — |
| 2072A | — | SB100B | YUV (DVP) | VGA | — | — |
| SN9C2730JG / SN9C2720M | SmartSens | SC030IOT | YUY2 / MJPG | ≤VGA | 30 fps | — |
| 2072A | SmartSens | SC030IOT | RAW (MIPI) | VGA | — | — |
| SN9C2805AJG | SmartSens | SC031GS | YUY2 / MJPG | ≤VGA | 120 fps | Global shutter |
| SN9C269M | SmartSens | SC031GS | YUY2 / MJPG | ≤VGA | 230 fps | MJPG 640×240 @230 fps; YUV 640×240 @60 fps; Global shutter |
| SN9C2279S | SmartSens | SC031GS | YUY2 / MJPG | ≤VGA | 60 fps | — |
| SN9C2805AJG | SmartSens | SC035HGS | YUY2 / MJPG | ≤VGA | 120 fps | Global shutter |
| SN9C2285A | SmartSens | SC035HGS | YUY2 / MJPG | ≤VGA | 60 fps | Color global shutter |
| SN9C2730JG / SN9C2720M | SmartSens | SC035HGS | YUY2 / MJPG | ≤VGA | 120 fps | Global shutter |
| 2282B (TNR) | SmartSens | SC035HGS | RAW / MIPI | VGA | 180 fps | Global shutter |
| SN9C2730JG / SN9C2720M | SmartSens | SC101IOT | YUY2 / MJPG | ≤720p | 30 fps | DVP |
| SN9C2730JG / SN9C2720M | SmartSens | SC1245 | YUY2 / MJPG | ≤720p | 30 fps | — |
| 2089D (with MIC) | SmartSens | SC130GS | RAW / MIPI | 1.3 MP | 80 fps | 1280×1024 |
| 2650A (with MIC) | SmartSens | SC130GS | RAW / MIPI | 1.3 MP | 170 fps | 1280×1024 |
| SN9C269M | SmartSens | SC132GS | YUY2 / MJPG | ≤960p | 30 fps | Global shutter |
| SN9C2279S | SmartSens | SC132GS | YUY2 / MJPG | 1072×1280 | 30 fps | — |
| 2089D (with MIC) | SmartSens | SC132GS | RAW / MIPI | 1.3 MP | — | 1088×1280 |
| 2650A (with MIC) | SmartSens | SC132GS | RAW / MIPI | 1.3 MP | 120 fps | 1088×1280 |
| 2688A (sync, with MIC) | SmartSens | SC1335T | RAW / MIPI | 1.2 MP | 90 fps | 1280×960 |
| 2075A / 2085A / 2087S (narrow-bezel) | SmartSens | SC1336 | RAW / MIPI | 1 MP | 60 fps | — |
| 2688A (sync, with MIC) | SmartSens | SC133HGS | RAW / MIPI | 1 MP | 60 fps | 1280×960 |
| SN9C2726S/M | SmartSens | SC1345 | YUY2/MJPG | ≤720p | 60 fps | — |
| SN9C2730JG / SN9C2720M | SmartSens | SC1345 | YUY2 / MJPG | ≤720p | 30 fps | — |
| 2075A / 2085A / 2087S (narrow-bezel) | SmartSens | SC1345 | RAW / MIPI | 1 MP | — | — |
| 2075A / 2085A / 2087S (narrow-bezel) | SmartSens | SC1346 / 1A4T | RAW / MIPI | 1 MP | — | — |
| SN9C2895Q | SmartSens | SC200AI | YUY2 / MJPG | ≤1080p | 30 fps | RGB |
| SN9C2905RJG | SmartSens | SC200AI | YUY2 / MJPG | ≤1080p | 60 fps | MIC; 3D-NR |
| SN9C2805AJG | SmartSens | SC200AI | YUY2 / MJPG | ≤1080p | 60 fps | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | SmartSens | SC200CS | RAW / MIPI | 2 MP | — | Max resolution: 1600×1200 |
| SN9C269M | SmartSens | SC200PC | YUY2 / MJPG | ≤1080p | 30 fps | — |
| 2075A / 2085A / 2087S (narrow-bezel) | SmartSens | SC200PC | RAW / MIPI | 1 MP | — | Max still: 1280×720 |
| 2282B / 2093N (narrow-bezel, TNR) | SmartSens | SC200PC | RAW / MIPI | 2 MP | — | Max still: 960×960; 500×500 up to ~300 fps (note) |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | SmartSens | SC200PC | RAW / MIPI | 2 MP | — | — |
| 2076A / 2111 (narrow-bezel, TNR) | SmartSens | SC201 / SC202CS | RAW / MIPI | 1 MP | — | — |
| 2282B / 2093N (narrow-bezel, TNR) | SmartSens | SC201 / SC202CS | RAW / MIPI | 2 MP | — | Max still: 1600×1200 |
| 2092C | SmartSens | SC201 / SC202CS | RAW / MIPI | 2 MP | — | Max still: 1600×1200 |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | SmartSens | SC201CS | RAW / MIPI | 2 MP | — | Max resolution: 1600×1200 |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | SmartSens | SC201CS | RAW / MIPI | 2 MP | — | Max res 1600×1200 |
| 2075A / 2085A / 2087S (narrow-bezel) | SmartSens | SC201CS / SC202 | RAW / MIPI | 1 MP | 60 fps | 202 / 60fps |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | SmartSens | SC202CS | RAW / MIPI | 2 MP | 720p @ 60 fps | — |
| 2092C | SmartSens | SC2045 | RAW / DVP | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | SmartSens | SC2045 | RAW / DVP | 2 MP | — | — |
| SN9C2279S | SmartSens | SC2145 | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| SN9C2805AJG | SmartSens | SC2210 | YUY2 / MJPG | ≤1080p | 60 fps | — |
| 2282B / 2093N (narrow-bezel, TNR) | SmartSens | SC2210 | RAW / MIPI | 2 MP | — | — |
| 2650A (built-in digital mic; AF optional) | SmartSens | SC2210 | RAW / MIPI | 2 MP (binned/ROI) | 60 fps | — |
| SN9C2279S | SmartSens | SC223A | YUY2 / MJPG | ≤1080p | 30 fps | MIC |
| 2282B / 2093N (narrow-bezel, TNR) | SmartSens | SC223A | RAW / MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | SmartSens | SC223A | RAW / MIPI | 2 MP | — | — |
| 2630A (USB3 normal) | SmartSens | SC230AI | RAW / MIPI | 2 MP | — | Digital zoom (in-SoC), optional AF |
| 2092C | SmartSens | SC2310 | RAW / MIPI | 2 MP | — | — |
| 2282B / 2093N (narrow-bezel, TNR) | SmartSens | SC2331 | RAW / MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | SmartSens | SC2331 | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | SmartSens | SC2331 | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | SmartSens | SC2331AT | RAW / MIPI | 2 MP | 60 fps | Automotive-grade sensor |
| 2282B / 2093N (narrow-bezel, TNR) | SmartSens | SC2336 | RAW / MIPI | 2 MP | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | SmartSens | SC2336 | RAW / MIPI | 2 MP | — | — |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | SmartSens | SC233A | RAW / MIPI | 2 MP | — | — |
| 2282B / 2093N (narrow-bezel, TNR) | SmartSens | SC233A / AP | RAW / MIPI | 2 MP | — | — |
| SN9C2805AJG | SmartSens | SC233HGS | YUY2 / MJPG | ≤1080p | 50 fps | Global shutter |
| 2688A (with MIC) | SmartSens | SC233HGS | RAW / MIPI | 2 MP | — | 1920×1080@90; 1280×720@160 |
| 2688A (sync, with MIC) | SmartSens | SC233HGS | RAW / MIPI | 2 MP | 60 fps | — |
| 2630A (USB3.0, with MIC) | SmartSens | SC233HGS | RAW / MIPI | 2 MP | 60 fps | 1920×1200 |
| SN9C2726S/M | SmartSens | SC2356 | YUY2/MJPG | ≤2 MP | 30 fps | — |
| 2076A / 2111 (narrow-bezel, TNR) | SmartSens | SC2363H | RAW / MIPI | 1 MP | — | — |
| SN9C2805AJG | SmartSens | SC301IOT | YUY2 / MJPG | ≤3 MP | 50 fps | — |
| 2630A (USB3 normal) | SmartSens | SC4010 | RAW / MIPI | 4 MP | — | Digital zoom (in-SoC), optional AF |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | SmartSens | SC4210 | RAW / MIPI | 3 MP | — | — |
| SN9C2805AJG | SmartSens | SC4336 | YUY2 / MJPG | ≤2K (≈2 MP) | 30 fps | — |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | SmartSens | SC4336P | RAW / MIPI | 4 MP | — | — |
| 2630A (USB3 normal) | SmartSens | SC500AI | RAW / MIPI | 5 MP | — | Digital zoom (in-SoC), optional AF |
| 2282B / 2093N (narrow-bezel, TNR) | SmartSens | SC500CS | RAW / MIPI | 2 MP (runs binned) | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | SmartSens | SC500CS | RAW / MIPI | 2 MP (binned) | — | note: legacy board claims 3 MP@20–25fps |
| 2099N narrow-bezel (no MIC) / 2281D (built-in digital zoom, AF optional) | SmartSens | SC500CS | RAW / MIPI | 2 MP (binned) | — | — |
| 2089D / 2150A2 (built-in digital mic; AF optional) | SmartSens | SC500CS | RAW / MIPI | 5 MP | — | — |
| 7500A / 2089D2 narrow-bezel (built-in digital mic; AF optional) | SmartSens | SC500CS | RAW / MIPI | 5 MP | — | — |
| SN9C2985S/R | SmartSens | SC501AI | YUY2 / MJPG | ≤5 MP | 30 fps | RGB; MIC |
| SN9C2905RJG | SmartSens | SC501AI | YUY2 / MJPG | ≤5 MP | 30 fps | MIC; 3D-NR |
| SN9C2805AJG | SmartSens | SC501AI | YUY2 / MJPG | ≤5 MP | 30 fps | MIC |
| 2120N | SmartSens | SC520CS | RAW (MIPI) | 5 MP | Windows Hello | RGB |
| 2150A2 | SmartSens | SC520CS | RAW (MIPI) | 5 MP | Windows Hello | RGB |
| 2089B | SmartSens | SC520CS | RAW (MIPI) | 5 MP | Windows Hello | RGB |
| 7500A | SmartSens | SC520CS | RAW (MIPI) | 5 MP | Windows Hello | RGB |
| 2282B / 2093N (narrow-bezel, TNR) | SmartSens | SC520CS | RAW / MIPI | 2 MP (runs binned) | — | — |
| 2281B5 / B3 / B2（Narrow bezel; CP with built-in digital zoom; B3/B5 with built-in module/lens, supporting AF） | SmartSens | SC520CS | RAW / MIPI | 2 MP (binned) | — | — |
| 2089D / 2150A2 (built-in digital mic; AF optional) | SmartSens | SC520CS | RAW / MIPI | 5 MP | — | — |
| 7500A / 2089D2 narrow-bezel (built-in digital mic; AF optional) | SmartSens | SC520CS | RAW / MIPI | 5 MP | — | — |
| SN9C2805AJG | SmartSens | SC5239 | YUY2 / MJPG | ≤5 MP | 30 fps | MIC |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | SmartSens | SC5239 | RAW / MIPI | 5 MP | — | — |
| SN9C5259AFG | SmartSens | SC5335P | YUY2 / MJPG | ≤5 MP | 25 fps | MIC |
| SN9C2805AJG | SmartSens | SC5335P | YUY2 / MJPG | ≤5 MP | 30 fps | MIC |
| SN9C2805AJG | SmartSens | SC5356 | YUY2 / MJPG | ≤5 MP | 30 fps | — |
| SN9C2808Z | SmartSens | SC535HGS | YUY2 / MJPG | ≤5 MP | 30 fps | Global shutter; MIC |
| 2688A (with MIC) | SmartSens | SC535HGS | RAW / MIPI | 5 MP | — | 2488×2048@47 |
| 2630A (USB3.0, with MIC) | SmartSens | SC535HGS | RAW / MIPI | 5 MP | 25 fps | 2432×2048; 1920×1200 @60 |
| 2089D / 2150A2 (built-in digital MIC, AF optional) | SmartSens | SC5531AI | RAW / MIPI | 5 MP | — | — |
| 2680A / 2680A1 (built-in digital mic, AF optional) | SmartSens | SC820CS | RAW / MIPI | 8 MP | — | — |
| SN9C2809E | SmartSens | SC8238 | YUY2 / MJPG | ≤4K (≈8.3 MP) | 30 fps | MIC |
| 2688A (built-in digital mic, AF optional) | SmartSens | SC8238 | RAW / MIPI | 4K video | — | — |
| 2688A (built-in digital mic, AF optional) | SmartSens | SC831HAI | RAW / MIPI | 4K video | — | — |
| 2072A | SiliconFile | SCO8BAB | RAW (MIPI) | VGA | — | — |
| 2072A | SiliconFile | SCO8BN | RAW (MIPI) | VGA | — | — |
| 2072A | SiliconFile | SCOA6K | RAW (DVP) | VGA | — | — |
| 2072A | SiliconFile | SCOA6R | RAW (DVP) | VGA | — | — |
| 2072A | SiliconFile | SCOA71 | RAW (DVP) | VGA | — | — |
| 2072A | SiliconFile | SCOA7A | RAW (MIPI) | VGA | — | — |
| 2072A | SiliconFile | SCOA7AA | RAW (MIPI) | VGA | — | — |
| 2072A | SiliconFile | SCOA7D | RAW (DVP) | VGA | — | — |
| 2072A | SiliconFile | SCOA7U | RAW (DVP) | VGA | — | — |
| 2072A | SiliconFile | SCOA82 | RAW (DVP) | VGA | — | — |
| 2072A | SiliconFile | SCOA83 | RAW (MIPI) | VGA | — | — |
| 2072A | SiliconFile | SCOE8X | RAW (MIPI) | VGA | — | — |
| 2075A / 2085A / 2087S (narrow-bezel) | SiliconFile | SIM130A | RAW / MIPI | 1 MP | — | — |
| CH9004/CH9005/CH9013 | SiliconFile | SIV121D | YUV / DVP | 0.3 MP | 480p 30fps | — |
| 2072A | SiliconFile | SIV121DU | YUV / DVP | VGA | — | — |
| 2680A / 2680A1 (built-in digital mic, AF optional) | Samsung / GalaxyCore | SK08A8 / GC08A8 | RAW / MIPI | 8 MP | — | — |
| 2688A (built-in digital mic, AF optional) | Samsung / GalaxyCore | SK13A0 / GC13A0 | RAW / MIPI | 13 MP class | — | — |
| SN9C259BFG | SOI | SK3AC | YUY2/MJPG | ≤3 MP | 15 fps | — |
| 2072A | SuperPix | SP0718 | YUV (DVP) | VGA | — | — |
| CH9004/CH9005/CH9021 | SuperPix | SP0718 | YUV / DVP | 0.3 MP | 480p 30fps | — |
| 2072A | SuperPix | SP0838 | YUV (DVP) | VGA | — | — |
| CH9004/CH9005/CH9022 | SuperPix | SP0839 | YUV / DVP | 0.3 MP | 480p 30fps | — |
| 2050A | SuperPix | SP0A18 | YUV (DVP) | VGA (≈0.3 MP) | — | — |
| 2072A | SuperPix | SP0A18 | YUV (DVP) | VGA | — | — |
| CH9004/CH9005/CH9017 | SuperPix | SP0A18 | YUV / DVP | 0.3 MP | 480p 30fps | — |
| SN9C263AJG | SuperPix | SP0A19 | YUY2 | ≤VGA | 30 fps | — |
| CH9004/CH9005/CH9018 | SuperPix | SP0A19 | YUV / DVP | 0.3 MP | 480p 30fps | — |
| CH9004/CH9005/CH9019 | SuperPix | SP0A20 | YUV / DVP | 0.3 MP | 480p 30fps | — |
| 2072A | SuperPix | SP0A28 | YUV / MIPI | VGA | — | — |
| 2050A | SuperPix | SP0A29 | YUV (DVP) | VGA (≈0.3 MP) | — | — |
| CH9004/CH9005/CH9020 | SuperPix | SP0A39 | YUV / DVP | 0.3 MP | 480p 30fps | — |
| SN9C2726S/M | SuperPix | SP1405 | YUY2/MJPG | ≤720p | 30 fps | — |
| SN9C2730JG / SN9C2720M | SuperPix | SP1405 | YUY2/MJPG | ≤720p | 30 fps | — |
| 2075A / 2085A / 2087S (narrow-bezel) | SuperPix | SP1405 | RAW / MIPI | 1 MP | — | — |
| 2075A / 2085A / 2087S (narrow-bezel) | SuperPix | SP140A | RAW / MIPI | 1 MP | — | — |
| 2072A | SuperPix | SP1618 | YUV (DVP) | VGA | — | — |
| SN9C2726S/M | SuperPix | SP2507 | YUY2/MJPG | ≤720p | 30 fps | — |
| SN9C2726S/M | SuperPix | SP2508 | YUY2/MJPG | ≤720p | 30 fps | — |
| SN9C2726S/M | SuperPix | SP2509 | YUY2/MJPG | ≤720p | 30 fps | — |
| 2072A | SuperPix | SP2509 | RAW (MIPI) | VGA | — | — |
| 2075A / 2085A / 2087S (narrow-bezel) | SuperPix | SP2509 | RAW / MIPI | 1 MP | — | — |
| 2075A / 2085A / 2087S (narrow-bezel) | SuperPix | SP2518 | YUV / DVP | 1 MP | — | — |
| CH9004/CH9005/CH9023 | SuperPix | SP2529 | YUV / DVP | 2 MP | 480p 30fps; 720p 10fps; 1200p 5fps | — |
| SN9C2730JG / SN9C2720M | STMicro | STI2250 | YUY2 / MJPG | ≤VGA | 60 fps | — |
| CH9004/CH9005/CH9012 | STMicro | STV100A | YUV / DVP | 0.3 MP | 480p 30fps | — |
